Features
Power supply: 220V AC +/- 15% 50 / 60Hz (24V AC; 110VAC available)
Power Consumption: 4VA (only when damper position changes)
Nominal angular rotation: 90.
Torque: 1 Nm
Ambient Temperature: 0~60oC
Relative Humidity: 0~90%
- Diameter: 150mm; 160mm;200mm;250mm;300mm,etc(other sizes optional )
- End switches
- Warmed by special thermal material with sound resistant fearures
- Painted in high temperature on green colour
- Customizing available

Application
- used in rooms where temportary higher or lower ventilation is requaied
(guest rooms, offices,etc)
- by using IBF model there is possibility to change ventilation level in separated
rooms or in block of rooms
- connected with special thermostat it can realize air cooling or heating (zone control)
- mounted on channel which transports air to fire place to control speed of
fire (middle positions) or close channel when fire place is not ued.
