System group
|
14 systems
|
Systems with one storage tank
|
System 1: 1 collector array – 1 storage tank
|
|
System 2: 1 collector array - 1 storage tank - heating return increase System 3: 1 collector array - 1 storage tank with external heat exchanger System 4: 1 collector array – 1 storage tank with zone loading
|
|
System 5: 2 collector arrays (east/west roof) – 1 storage tank
|
Systems with two storage tanks
|
System 6: 1 collector array – 2 storage tanks – intelligent pump control System 7: 1 collector array – 2 storage tanks – intelligent valve control
|
Systems with a swimming pool
|
System 8: 1 collector array – 1 swimming pool
|
|
System 9: 1 collector array - 1 swimming pool with external heat exchanger System 10: 1 collector array - 1 swimming pool in stand-alone operation with external heat exchanger
|
|
System 11: 2 collector arrays (east/west roof) - 1 swimming pool
|
|
System 12: 2 collector arrays (east/west roof) - 1 swimming pool in stand-alone operation with external heat exchanger
|
Systems with one storage tank and a swimming pool
|
System 13: 1 collector array - 1 storage tank - 1 swimming pool in stand-alone operation with external heat exchanger - intelligent pump control
|
System 14: 1 collector array - 1 storage tank - 1 swimming pool in stand-alone operation with external heat exchanger - intelligent valve control
|
