Insbud Controls Company Limited

Features

* Large LCD display
* Extra slim and compact control panel
* 5/2 day or 7 day programmable
* Manual temporay override and vacation mode
* Frost protection function
* White backlight / Blue back light optional
* White,silver plastic finishes optional
* F / C temperature format can be selected
* 12/24 Hour clock format can be selected
* Programmes and settings can be reserved after power break
* Adjustable switching differential
* Firmware can be upgraded
* Customizing welcome


Specifications

* Power supply: 230VAC
* Inputs: 1x NTC10K temperature sensor
* Output: 1 x dry contact relay(R1),max 3A
* Ambient temperature: 0 °C [+32 °F] ~ +45 °C [+113 °F]
* Operating RH: 0~95% (non condensing).
* Dimensions: 86mm x 86mm x13mm
* Display Size: 65 x 48mm.
* Backlight life: 5,000 hours.
* Battery type: CR 1220 (Backs up clock only)
* Battery life: > 5years (10 years Maximum)


User manual download
